QH-TDUNR/L : Exchangeable boring heads with 55° DN...1504/06 inserts & 93° approach angle for anti-vibration deep boring


  DesignationDCONMS LF WF DMIN  R/L d t Kr K CL Tool typ ClssID MIID CCTMS CCFMS LTA IIC IIC_2 IIC_3 IIC_4 IIC_5 GICATGIREMgiicGICODE
  QH40-TDUNL-1504 40.0038.0027.0050.00O ~L ~12.70~4.76~0~93.0~SCREW ~ADAPTER ~71E01A0E9CBA9 ~DNGA 150408 CMS ~01 ~38.00~IS$$231914955097111 ~IS$$383577274516228 ~IS$$493442649564267 ~IS$$581084907694694 ~ ~6255428 0
  QH40-TDUNL-1506 40.0038.0027.0050.00O ~L ~12.70~6.35~0~93.0~SCREW ~ADAPTER ~71E01A0E9CBA9 ~DNGA 150608 CMS ~01 ~38.00~IS$$401217296969863 ~IS$$607984142147679 ~IS$$695105559106321 ~IS$$808521261787470 ~IS$$850587966573147 ~6262318 0
  QH40-TDUNR-1504 40.0038.0027.0050.00O ~R ~12.70~4.76~0~93.0~SCREW ~ADAPTER ~71E01A0E9CBA9 ~DNGA 150408 CMS ~01 ~38.00~IS$$242400693101226 ~IS$$383577274516228 ~IS$$493442649564267 ~IS$$581084907694694 ~ ~6255429 0
  QH40-TDUNR-1506 40.0038.0027.0050.00O ~R ~12.70~6.35~0~93.0~SCREW ~ADAPTER ~71E01A0E9CBA9 ~DNGA 150608 CMS ~01 ~38.00~IS$$384556734858845 ~IS$$607984142147679 ~IS$$695105559106321 ~IS$$808521261787470 ~IS$$850587966573147 ~6263865 0
When applying 50mm shank, Dmin for the assembly is 60mm.
When applying 60mm shank, Dmin for the assembly is 70mm.
