TaeguTec Cutting Tools - Metal Working Tools - Boring System -

KIT BHF-MB : Fine boring head set: one fine boring head with precision 0.002 mm diametric adjustment & various boring tool holders and inserts

Designation	SS	d Range	DCN	DCX	DCONMS	RPMX	GICAT
KIT BHF MB50-50 6-140	MB50	6-140	6.00	140.00	50.00	8000	6283386
KIT BHF MB50-63 6-155	MB50	6-155	6.00	155.00	50.00	8000	6282462
KIT BHF MB50-80 6-220	MB50	6-220	6.00	220.00	50.00	8000	4652559
KIT BHF MB63-63 6-155	MB63	6-155	6.00	155.00	63.00	6000	6293952
KIT BHF MB80-80 6-220	MB80	6-200	6.00	220.00	80.00	5000	4652563

For kit contents and boring options, click on "More Info"
