TaeguTec Cutting Tools - Metal Working Tools - Turning -

SNMG-MM (RHINO) : Negative Square RHINOTURN inserts for general machining of stainless steels & steels

Designation	IC	S	RE	CBMD	alpha	AN	ap (min)	ap (max)	ft (min)	ft (max)	CEDC	Precise	Utility	l	SC	ClssID	RHINO	COATP	GRDMFG	IFS	IIC	INSI	INST	ISO STD	SSC	GICAT	GIREM	giic	GICODE	Tough ‹————› Hard Grade & Vc Click on grade for cutting speed value
SNMG 090404 MM	9.52	4.76	0.40	MM ~	90~	0.00~	0.40	3.00	0.15	0.45	8~	~	U ~	9.52~	S ~	71DD68D829217 ~	RHINO-TURN ~	CVD ~	TT9215~	2~	ISO$SN0904042NB$$04 ~	331 MM ~	SNMG ~	Y ~	9 ~	6118394		1		TT9215
SNMG 090408 MM	9.52	4.76	0.80	MM ~	90~	0.00~	0.50	3.00	0.20	0.50	8~	~	U ~	9.52~	S ~	71DD68D829217 ~	RHINO-TURN ~	CVD ~	8115B ~	2~	ISO$SN0904082NB$$08 ~	332 MM ~	SNMG ~	Y ~	9 ~	6242329		5		TT9225 TT5100 TT8125B TT5080 TT8115B
