| 06IR 26 W | 3.97 | 26.0 | 6.00 | 0.10 | 0.7 | 0.6 | T ~ | 71DDA089C8D1E ~ | R ~ | TT8010~ | IS$$29185877246820 ~ | 5922426 | | 1 | | TT8010 |
| 08IR 16 W | 4.76 | 16.0 | 8.00 | 0.18 | 0.6 | 0.7 | T ~ | 71DDA089C8D1E ~ | R ~ | TT8010~ | IS$$87556722573312 ~ | 5922583 | | 1 | | TT8010 |
| 08IR 18 W | 4.76 | 18.0 | 8.00 | 0.16 | 0.6 | 0.7 | T ~ | 71DDA089C8D1E ~ | R ~ | TT8010~ | IS$$87556722573312 ~ | 5922487 | | 1 | | TT8010 |
| 08IR 19 W | 4.76 | 19.0 | 8.00 | 0.16 | 0.6 | 0.7 | T ~ | 71DDA089C8D1E ~ | R ~ | TT8010~ | IS$$87556722573312 ~ | 6217602 | | 2 | | TT8010 TT9030 |
| 08IR 28 W | 4.76 | 28.0 | 8.00 | 0.12 | 0.5 | 0.6 | T ~ | 71DDA089C8D1E ~ | R ~ | TT8010~ | IS$$87556722573312 ~ | 6147396 | | 1 | | TT8010 |
| 11IL 14 W | 6.35 | 14.0 | 11.00 | 0.23 | 0.9 | 1.1 | T ~ | 71DDA089C8D1E ~ | L ~ | TT9030~ | IS$$163576655600280 ~ | 6305387 | | 1 | | TT9030 |
| 11IR 14 W | 6.35 | 14.0 | 11.00 | 0.23 | 0.9 | 1.1 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$163576067316584 ~ | 5922106 | | 3 | | TT8010 TT7010 TT9030 |
| 11IR 16 W | 6.35 | 16.0 | 11.00 | 0.18 | 0.9 | 1.1 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$163576067316584 ~ | 5922265 | | 1 | | TT9030 |
| 11IR 18 W | 6.35 | 18.0 | 11.00 | 0.18 | 0.8 | 1.0 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$163576067316584 ~ | 5922268 | | 1 | | TT9030 |
| 11IR 19 W | 6.35 | 19.0 | 11.00 | 0.18 | 0.8 | 0.9 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$163576067316584 ~ | 5922160 | | 2 | | TT7010 TT9030 |
| 11IR 20 W | 6.35 | 20.0 | 11.00 | 0.14 | 0.8 | 0.9 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$163576067316584 ~ | 5922269 | | 2 | | TT7010 TT9030 |
| 11IR 24 W | 6.35 | 24.0 | 11.00 | 0.15 | 0.8 | 0.8 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$163576067316584 ~ | 5922413 | | 1 | | TT9030 |
| 11IR 26 W | 6.35 | 26.0 | 11.00 | 0.12 | 0.6 | 0.6 | T ~ | 71DDA089C8D1E ~ | R ~ | TT8010~ | IS$$163576067316584 ~ | 5921765 | | 1 | | TT8010 |
| 11IR 28 W | 6.35 | 28.0 | 11.00 | 0.13 | 0.6 | 0.6 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$163576067316584 ~ | 5921427 | | 1 | | TT7010 |
| 16IR 8 W | 9.52 | 8.0 | 16.00 | 0.41 | 1.1 | 1.1 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922147 | | 1 | | TT9030 |
| 16IR 9 W | 9.52 | 9.0 | 16.00 | 0.34 | 1.2 | 1.7 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$656439147860736 ~ | 5921689 | | 1 | | TT7010 |
| 16IR 10 W | 9.52 | 10.0 | 16.00 | 0.32 | 1.1 | 1.1 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922083 | | 1 | | TT9030 |
16IRB 10 W  | 9.52 | 10.0 | 16.00 | 0.31 | 1.1 | 1.5 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 6111441 | With pressed chip breaker | 1 | | TT9030 |
| 16IL 11 W | 9.52 | 11.0 | 16.00 | 0.29 | 1.1 | 1.5 | T ~ | 71DDA089C8D1E ~ | L ~ | TT9030~ | IS$$627253136918045 ~ | 5922437 | | 1 | | TT9030 |
| 16IR 11 W | 9.52 | 11.0 | 16.00 | 0.29 | 1.1 | 1.5 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$656439147860736 ~ | 5921973 | | 3 | | TT8010 TT7010 TT9030 |
| 16IRB 11 W | 9.52 | 11.0 | 16.00 | 0.28 | 1.1 | 1.5 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 6111444 | With pressed chip breaker | 1 | | TT9030 |
| 16IRM 11 W | 9.52 | 11.0 | 16.00 | 0.27 | 1.1 | 1.5 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$656439147860736 ~ | 5920137 | With pressed chip breaker | 2 | | TT7010 TT9030 |
| 16IR 12 W | 9.52 | 12.0 | 16.00 | 0.27 | 1.2 | 1.5 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922019 | | 1 | | TT9030 |
| 16IL 14 W | 9.52 | 14.0 | 16.00 | 0.23 | 1.0 | 1.2 | T ~ | 71DDA089C8D1E ~ | L ~ | TT9030~ | IS$$627253136918045 ~ | 5922427 | | 1 | | TT9030 |
| 16IR 14 W | 9.52 | 14.0 | 16.00 | 0.23 | 1.0 | 1.2 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$656439147860736 ~ | 5921832 | | 3 | | TT8010 TT7010 TT9030 |
| 16IR 14 W 2M | 9.52 | 14.0 | 16.00 | 0.23 | 1.7 | 2.6 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922626 | Multi-tooth | 1 | | TT9030 |
| 16IRB 14 W | 9.52 | 14.0 | 16.00 | 0.23 | 1.0 | 1.2 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 6111449 | With pressed chip breaker | 1 | | TT9030 |
| 16IRM 14 W | 9.52 | 14.0 | 16.00 | 0.21 | 1.0 | 1.2 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$656439147860736 ~ | 6224434 | With pressed chip breaker | 2 | | TT7010 TT9030 |
| 16IR 16 W | 9.52 | 16.0 | 16.00 | 0.20 | 1.0 | 1.0 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5921577 | | 1 | | TT9030 |
| 16IRB 16 W | 9.52 | 16.0 | 16.00 | 0.20 | 1.0 | 1.2 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 6111451 | With pressed chip breaker | 1 | | TT9030 |
| 16IRM 16 W | 9.52 | 16.0 | 16.00 | 0.18 | 0.9 | 1.1 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5920159 | With pressed chip breaker | 1 | | TT9030 |
| 16IR 18 W | 9.52 | 18.0 | 16.00 | 0.18 | 0.8 | 0.8 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922013 | | 1 | | TT9030 |
| 16IL 19 W | 9.52 | 19.0 | 16.00 | 0.00 | 0.0 | 0.0 | T ~ | 71DDA089C8D1E ~ | L ~ | TT9030~ | IS$$627253136918045 ~ | 6334250 | | 1 | | TT9030 |
| 16IR 19 W | 9.52 | 19.0 | 16.00 | 0.17 | 0.7 | 0.8 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$656439147860736 ~ | 5922653 | | 2 | | TT7010 TT9030 |
| 16IRB 19 W | 9.52 | 19.0 | 16.00 | 0.17 | 0.7 | 0.8 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 6111453 | With pressed chip breaker | 1 | | TT9030 |
| 16IRM 19 W | 9.52 | 19.0 | 16.00 | 0.15 | 0.8 | 1.0 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$656439147860736 ~ | 5920173 | With pressed chip breaker | 1 | | TT7010 |
| 16IR 20 W | 9.52 | 20.0 | 16.00 | 0.16 | 0.7 | 0.8 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922335 | | 1 | | TT9030 |
| 16IRM 20 W | 9.52 | 20.0 | 16.00 | 0.14 | 0.8 | 0.9 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922580 | With pressed chip breaker | 1 | | TT9030 |
| 16IR 24 W | 9.52 | 24.0 | 16.00 | 0.11 | 0.7 | 0.8 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922014 | | 1 | | TT9030 |
| 16IR 26 W | 9.52 | 26.0 | 16.00 | 0.12 | 0.8 | 0.8 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$656439147860736 ~ | 5922390 | | 1 | | TT9030 |
| 16IR 28 W | 9.52 | 28.0 | 16.00 | 0.09 | 0.6 | 0.7 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$656439147860736 ~ | 5921470 | | 1 | | TT7010 |
| 16IR 32 W | 9.52 | 32.0 | 16.00 | 0.09 | 0.6 | 0.6 | T ~ | 71DDA089C8D1E ~ | R ~ | P30 ~ | IS$$656439147860736 ~ | 5920860 | | 1 | | P30 |
| 22IR 5 W | 12.70 | 5.0 | 22.00 | 0.65 | 1.7 | 2.4 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$350757975214911 ~ | 5922337 | | 1 | | TT7010 |
| 22IR 6 W | 12.70 | 6.0 | 22.00 | 0.52 | 1.6 | 2.3 | T ~ | 71DDA089C8D1E ~ | R ~ | TT7010~ | IS$$350757975214911 ~ | 5922115 | | 1 | | TT7010 |
| 22IR 7 W | 12.70 | 7.0 | 22.00 | 0.45 | 1.6 | 2.3 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$350757975214911 ~ | 5922667 | | 1 | | TT9030 |
| 22IR 11 W 2M | 12.70 | 11.0 | 22.00 | 0.09 | 2.3 | 3.4 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | IS$$350757975214911 ~ | 5922628 | Multi-tooth | 1 | | TT9030 |
| 27IR 4 W | 15.88 | 4.0 | 27.00 | 0.82 | 2.0 | 2.9 | T ~ | 71DDA089C8D1E ~ | R ~ | TT9030~ | ~ | 5922706 | | 1 | | TT9030 |
